The DATEXEL DAT6000 series is an evolution in the connection of analog signals to digital PLC's.
The DATEXEL DAT6011 converts two non isolated Voltages (up to ± 1 V) or thermocouple signals to a digital PLC.
The DATEXEL DAT6000 series amplifies, linearizes, isolates, filters and converts the analog signals to a high resolution digital signal, by few and simple instructions downloaded into any PLC. It is possible to acquire more analog signals on one digital input.
The digital signal can be connected to any input of the PLC. The digital signal is composed of a series of 16 bits “word” containing the value of the analog inputs to acquire. The PLC controls the data transmission by a clock signal (CLK) generated from one of its output ports used to ask the device after the enabling of transmission by the enable signal (ENABLE). If the enable signal is high, at each rising edge of clock, the device will provide on the data line (DATA) one of the bits that composes the reading word.
